Microstrip Isolator

There are 43 related products in the Microstrip Isolator category
  • Parametric Search
  • Download Datasheets
  • Get Quotations
  • Description: 22.0 to 32.0 GHz Microstrip Isolator
  • Frequency Range: 37.0~43.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 1.4 dB
  • Isolation Min: 14.0 dB
  • Forward Power: 2 W
  • Reverse Power: 2 W
  • Description: 22.0 to 32.0 GHz Microstrip Isolator
  • Frequency Range: 24.0~40.0 GHz
  • Bandwidth Max: 15%
  • Insertion Loss Max: 0.7~0.90 dB
  • Isolation Min: 15.0 dB
  • Forward Power: 15 W
  • Reverse Power: 4 W
  • Description: 22.0 to 32.0 GHz Microstrip Isolator
  • Frequency Range: 24.0~40.0 GHz
  • Bandwidth Max: 15%
  • Insertion Loss Max: 0.7~0.90 dB
  • Isolation Min: 15.0 dB
  • Forward Power: 15 W
  • Reverse Power: 2 W
  • Description: 22.0 to 32.0 GHz Microstrip Isolator
  • Frequency Range: 22.0~32.0 GHz
  • Bandwidth Max: 25%
  • Insertion Loss Max: 0.7 dB
  • Isolation Min: 17.0 dB
  • Forward Power: 2 W
  • Reverse Power: 2 W
  • Description: 18.0 to 24.0 GHz Microstrip Isolator
  • Frequency Range: 18.0~22.0 GHz
  • Bandwidth Max: 20%
  • Insertion Loss Max: 0.6 dB
  • Isolation Min: 17.0 dB
  • Forward Power: 2 W
  • Reverse Power: 2 W
  • Description: 14.0 to 40.0 GHz Microstrip Isolator
  • Frequency Range: 14.0~40.0 GHz
  • Bandwidth Max: 20%
  • Insertion Loss Max: 0.50~0.70 dB
  • Isolation Min: 18.0~20.0 dB
  • Forward Power: 10 W
  • Reverse Power: 3 W
  • Description: 11.0 to 18.0 GHz Microstrip Isolator
  • Frequency Range: 11.0~18.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.90 dB
  • Isolation Min: 15.0 dB
  • Forward Power: 15 W
  • Reverse Power: 3 W
  • Description: 8.0 to 18.0 GHz Microstrip Isolator
  • Frequency Range: 8.0~18.0 GHz
  • Bandwidth Max: 45%
  • Insertion Loss Max: 0.50~0.90 dB
  • Isolation Min: 12.0~20 dB
  • Forward Power: 15 W
  • Reverse Power: 3 W
  • Description: 8.0 to 12.0 GHz Microstrip Isolator
  • Frequency Range: 8.0~12.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.60 dB
  • Isolation Min: 18.0 dB
  • Forward Power: 10 W
  • Reverse Power: 3 W
  • Description: 8.0 to 12.0 GHz Microstrip Isolator
  • Frequency Range: 8.0~12.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.60 dB
  • Isolation Min: 17.0 dB
  • Forward Power: 10 W
  • Reverse Power: 3 W
  • Description: 7.0 to 12.0 GHz Microstrip Isolator
  • Frequency Range: 7.0~12.0 GHz
  • Bandwidth Max: 40%
  • Insertion Loss Max: 0.50~0.60 dB
  • Isolation Min: 18.0~20.0 dB
  • Forward Power: 15 W
  • Reverse Power: 5 W
  • Description: 6.0 to 18.0 GHz Microstrip Isolator
  • Frequency Range: 6.0~18.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 1.00~1.30 dB
  • Isolation Min: 14.0~15.0 dB
  • Forward Power: 16 W
  • Reverse Power: 2 W
