Waveguide Isolator

There are 26 related products in the Waveguide Isolator category
  • Parametric Search
  • Download Datasheets
  • Get Quotations
  • Description: 17.7 to 21.6 GHz Waveguide Isolator
  • Frequency Range: 17.7~21.6 GHz
  • Bandwidth Max: 90%
  • Insertion Loss Max: 0.30dB
  • Isolation Min: 20.0 dB
  • Forward Power: 30 W
  • Reverse Power: 15 W
  • Description: 12.4 to 18.0 GHz Waveguide Isolator
  • Frequency Range: 12.4~18.0 GHz
  • Bandwidth Max: 20%
  • Insertion Loss Max: 0.30~0.35 dB
  • Isolation Min: 20.0~23.0 dB
  • Forward Power: 100 W
  • Reverse Power: 30 W
  • Description: 12.0 to 18.0 GHz Waveguide Isolator
  • Frequency Range: 12.0~18.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.40 dB
  • Isolation Min: 20.0 dB
  • Forward Power: 100 W
  • Reverse Power: 30 W
  • Description: 10.0 to 15.0 GHz Waveguide Isolator
  • Frequency Range: 10.0~15.0 GHz
  • Bandwidth Max: 20%
  • Insertion Loss Max: 0.30~0.35 dB
  • Isolation Min: 20.0~23.0 dB
  • Forward Power: 100 W
  • Reverse Power: 30 W
  • Description: 8.0 to 12.4 GHz Waveguide Isolator
  • Frequency Range: 8.0~12.4 GHz
  • Bandwidth Max: 25%
  • Insertion Loss Max: 0.25~0.50 dB
  • Isolation Min: 18.0~23.0 dB
  • Forward Power: 100 W
  • Reverse Power: 30 W
  • Description: 8.0 to 12.0 GHz Waveguide Isolator
  • Frequency Range: 8.0~12.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.50 dB
  • Isolation Min: 18.0 dB
  • Forward Power: 100 W
  • Reverse Power: 30 W
  • Description: 7.0 to 10.0 GHz Waveguide Isolator
  • Frequency Range: 7.0~10.0 GHz
  • Bandwidth Max: 20%
  • Insertion Loss Max: 0.25~0.40 dB
  • Isolation Min: 20.0~25.0 dB
  • Forward Power: 100 W
  • Reverse Power: 30 W
  • Description: 5.4 to 8.0 GHz Waveguide Isolator
  • Frequency Range: 5.4~8.0 GHz
  • Bandwidth Max: 20%
  • Insertion Loss Max: 0.25~0.40 dB
  • Isolation Min: 18.0~25.0 dB
  • Forward Power: 100 W
  • Reverse Power: 30 W
  • Description: 18.0 to 26.5 GHz Waveguide Isolator
  • Frequency Range: 18.0~26.5 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.20 dB
  • Isolation Min: 20.0 dB
  • Forward Power: 100 W
  • Reverse Power: 20 W
  • Description: 34.0 to 36.0 GHz Waveguide Isolator
  • Frequency Range: 43.0~46.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.25 dB
  • Isolation Min: 18.0 dB
  • Forward Power: /
  • Reverse Power: /
  • Description: 34.0 to 36.0 GHz Waveguide Isolator
  • Frequency Range: 34.0~36.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.25 dB
  • Isolation Min: 18.0 dB
  • Forward Power: /
  • Reverse Power: /
  • Description: 26.0 to 40.0 GHz Waveguide Isolator
  • Frequency Range: 26.0~40.0 GHz
  • Bandwidth Max: 100%
  • Insertion Loss Max: 0.40~0.45 dB
  • Isolation Min: 16.0~20.0 dB
  • Forward Power: /
  • Reverse Power: /
