UIYWI4893A

by Waveguide-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Waveguide Isolator for global customers. UIYWI4893A is a Waveguide Isolator in Frequency Range of 8.0~12.0 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 100%, Insertion Loss Max is 0.50 dB and Isolation Min is 18.0 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of 100 W.

Product Specifications

Product Details

  • Part Number
    UIYWI4893A
  • Description
    8.0 to 12.0 GHz Waveguide Isolator

General Parameters

  • Frequency Range
    8.0~12.0 GHz
  • Bandwidth Max
    100%
  • Insertion Loss Max
    0.50 dB
  • Isolation Min
    18.0 dB
  • Forward Power
    100 W
  • Reverse Power
    30 W
  • VSWR Max
    1.30
  • Impedance
    50 Ω
  • Connector Type
    WR90(BJ100)
  • Size
    48×93×42 mm
  • Weight
    /
  • Operating Temperature
    -40~+85 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes
