UIYBDI14272A

by Dual-Junction-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Dual Junction Isolator for global customers. UIYBDI14272A is a Dual Junction Isolator in Frequency Range of 1.0~2.0 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 100%, Insertion Loss Max is 1.40 dB and Isolation Min is 34.0 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of 300 W.

Product Specifications

Product Details

  • Part Number
    UIYBDI14272A
  • Description
    1.0 to 2.0 GHz Dual Junction Isolator

General Parameters

  • Frequency Range
    1.0~2.0 GHz
  • Bandwidth Max
    100%
  • Insertion Loss Max
    1.40 dB
  • Isolation Min
    34.0 dB
  • Forward Power
    300 W
  • Reverse Power
    30 W
  • VSWR Max
    1.35
  • Impedance
    50 Ω
  • Connector Type
    TAB
  • Size
    144×72×27.4 mm
  • Weight
    /
  • Operating Temperature
    +10~+70 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes
