UIYBDI1716B

by Dual-Junction-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Dual Junction Isolator for global customers. UIYBDI1716B is a Dual Junction Isolator in Frequency Range of 12.0~18.0 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 100%, Insertion Loss Max is 1.20 dB and Isolation Min is 36.0 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of 30 W.

Product Specifications

Product Details

  • Part Number
    UIYBDI1716B
  • Description
    12.0 to 18.0 GHz Dual Junction Isolator

General Parameters

  • Frequency Range
    12.0~18.0 GHz
  • Bandwidth Max
    100%
  • Insertion Loss Max
    1.20 dB
  • Isolation Min
    36.0 dB
  • Forward Power
    30 W
  • Reverse Power
    2 W
  • VSWR Max
    1.35
  • Impedance
    50 Ω
  • Connector Type
    TAB
  • Size
    17.6×16.5×7.5 mm
  • Weight
    /
  • Operating Temperature
    -55~+85 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes
