UIYBDI4222A

by Dual-Junction-Isolator
RFHB04G18GPI Image

RF Solution offer a wide selection of Dual Junction Isolator for global customers. UIYBDI4222A is a Dual Junction Isolator in Frequency Range of 4.0~8.0 GHz. It is made of high quality materials under a high standard, the Bandwidth Max of this product is 100%, Insertion Loss Max is 1.00 dB and Isolation Min is 36.0 dB. The component has a good working performance and stability, it is ideal for handling a Forward Power of 100 W.

Product Specifications

Product Details

  • Part Number
    UIYBDI4222A
  • Description
    4.0 to 8.0 GHz Dual Junction Isolator

General Parameters

  • Frequency Range
    4.0~8.0 GHz
  • Bandwidth Max
    100%
  • Insertion Loss Max
    1.00 dB
  • Isolation Min
    36.0 dB
  • Forward Power
    100 W
  • Reverse Power
    20 W
  • VSWR Max
    1.30
  • Impedance
    50 Ω
  • Connector Type
    TAB
  • Size
    42×22.5×15 mm
  • Weight
    /
  • Operating Temperature
    -55~+85 ℃
  • Storage Temperature
    /
  • ROHS Compliant
    Yes
